Rated frequency

50 Hz

Phase

single-phase

three-phase

Power factor (cosΦ)

1.0

0.8 (lag)

Rated voltage

230 V

400/230 V

Rated output

9.0 kVA (9 kW)

11.0 kVA (9 kW)

Max. output

10.0 kVA (10 kW)

12.0 kVA (10 kW)

Rated current

39.1 A

15.8 A

Fuel Tank Capacity

25 L

Fuel Consumption (100% load)

330 g/kW.h (3.5 L/h)

Fuel Consumption (75% load)

297 g/kW.h (2.4 L/h)

Structure Mode

ultra silent

Dry Weight

320 kg

Overall Dimension (Lxlxh)

1200 x 650 x 760 mm

Noise level (LwA)

94 dB(A)

Engine model

2V80

Engine type

V-twin, water cooled, 4-stroke diesel engine

Aspiration

Natural

Governor

Mechanical

Max. power

12.5 kW

Rated speed

3000 rpm

Bore× Stroke

80 x 79 mm

Displacement

0.749 L

Compression ratio

18:1

Starting mode

12V electric

Battery capacity

36 Ah

Oil capacity

2.27 L

Oil type

SAE 15W-30, 15W-40

Fuel type

Diesel 0#(summer) -10#(winter) -35# (chilly winter)

Alternator model

KTDS-10

Alternator type

2 pole, synchronous, full power AC alternator

Rated power

10 kW

Rated speed

3000 rpm

Rated voltage

230/400 V

Efficiency

84%

Insulation grade

F

Protection level

IP21
